satelite gps tracking device gsm vehicle gps mobile tracker

Mini obd gps tracker for cars

G500M

mini obd gps tracker for cars
without diagnostic function
real time tracking
track through sms and platform.

Description
Specifications

G500M OBD gps car tracker
Real time tracking by sms/platform
over speed/geo fence/acc on alarm
power cut alarm with built in battery
support memorty storage when gsm signal lost
turning point location upload
remote voice monitoring

Network:GSM/GPRS

Content	Specs.
Dim.	50mm x 38mmx25mm
OBD Port	Support 16 pin standard OBDII port.
Network	GSM/GPRS
Frequency	850/900/1800/1900 MHz
GPS chipset	MTK high sensitivity chip
GPS channel	66
Tracking sensitivity	-165dBm
Location accuracy	<10 meters CEP
Time To First Fix(open sky)	Cold status <35s Hot status <1s
Working voltage	9-36VDC
GPRS Protocol	Class12, TCP/IP
Operating temp.	-20°C to +70°C
Standby & Working consumption	5mA~50mA
GSM / GPS antenna	Built-in
G-Sensor	Support
Geo-fence	Support
Angle change upload location	Support
Ignition status detection	Support
Memory Capacity	1400 positions

Mini obd gps tracker for cars

G500M
